Photovoltaic PV:12.5KW/300V
Rated power :8KW
Voltage level:48V
Minimum operating power :3KW
Production capacity :125Kg/h
Control Model :automatic
(One) Main technical parameters
1. Hourly yield : 125 kg corn flour.
2. Power : 6.9 KW
3. Dimension : Length × width × height 2755mm × 1650 × 3900mm
(Two) Name and specification of main equipment
No. | Name | Specifications | Unit | Packages | Remarks | ||||
1 | Mill | 2235 type | stand | 1 | |||||
2 | Milling roller | 220×350 | piece | 2 | |||||
3 | Square plansifter | FSFG1×5 type | set | 1 | |||||
Detailed parameters of mill roller | |||||||||
No. | Name | Parameter | No. | Name | Parameter | ||||
1 | Roller diameter | Φ220mm | 4 | The fastest rotational speed of milling roll | 720rpm | ||||
2 | Roller length | 350mm | 5 | The slowest speed of milling roller | 300rpm | ||||
3 | Roller speed ratio | 2.4:1 | 6 | Feeding roll feeding mode | Uniform feeding | ||||
(Three) Characteristic
1. High-efficiency square plansifter technology, natural screening without external force, uniform particle size.
2. The sieve plate can be selected according to different materials and requirements to realize one-off screening. It is suitable for processing of corn, wheat, sorghum and other kinds of grain. It has wide applicability and flexible sieve path.
3. One click to start, fully automatic operation, finish the whole working procedure of feeding, peeling, grinding and screening powder automatically, it minimizes labor and reduces the intensity of work.
4. With CCS management, it can realize the automatic regulation of the load following the solar power when the photovoltaic power supply is realized, the minimum operating power is only 3 kW, which greatly improves the efficiency of solar energy utilization.
